Page 37 - A5

Technical specificaTions Technical specificaTions

BRAUN binoculars excel in robustness,
modern design and high-quality optics.

Folder page
Leisure + travel • • • • •
Events • • • • •
Outdoor • • • • •
Bird + game watching, hunting • • • • •
Astronomy • • • • •
Magnification 8x 10–30x 8-24x 16x 12x
Lens system ULTRALIT ® ULTRALIT ® ULTRALIT ® ULTRALIT ® ULTRALIT ®
Lens diameter 42 mm 60 mm 50 mm 50 mm 50 mm
Light value 27.6 33.6-4 38.4 - 4.4 7.8 13
Twilight number 18.3 24.5–42.4 20.0 - 34.6 28.3 24.5
Prism Roof BAK-4 Porro BK 7 Porro, BK 7 Porro BK 7 Porro BK 7
Lens coating • • • • •
Focusing Central Central Central Central Central
Exit pupil 5.25 mm 5.8–2 mm 2.1-6.2 mm 2.8 mm 3.6 mm
Eye relief 18 mm 4.5–11.7 mm 12.5-16.5 mm 6.6 mm 12.0 mm
Field of view 7.0°, 112 m / 1000 m 2.0–3.6°, 62–34 m / 1000 m 4.5°-2.3°, 78-40 m / 1000 m 4.2°, 73 m / 1000 m 5.2°, 92 m / 1000 m

Close focus distance 13 m 15 m 10 m 10 m 10 m
Diopter adjustment -4 / +4 -4 / +4 -2 / +2 -4 / +4 -4 / +4
Interpupillary distance 56 -74 mm 56–74 mm 56 -72 mm 56–74 mm 56–74 mm
Waterproof (max. depth/time) 0.5 m / 20 min. ° ° ° °
Nitrogen filled • ° ° ° °
Eyecup system Rubber pop-up 2 Rubber pop-up 1 Rubber pop-up 1 Rubber pop-up 1 Rubber pop-up 1
Thread for tripod ° • • • •
Dimensions 61 x 65 x 143 mm 245 x 165 x 78 mm 190 x 190 x 65 mm 157 x 184 x 60 mm 157 x 184 x 60 mm
Weight 340 g 1100 g 850 g 790 g 790 g
Item no. / EAN 20140 / 40 00567 20140 3 20117 / 40 00567 20117 5 20168 / 40 00567 20168 7 20124 / 40 00567 20124 3 20125 / 40 00567 20125 0
Accessories: Ever-ready case, carrying strap, cleaning cloth, operating instructions.
•
Legend: = yes, ° = no, = fold down eyecups, = twist-type snap-on eyecups
